| List of Technical Parameters of Curb Polishing Machine | |||||||
| Designation | Model | Technical characteristics (length*width) | Components | Quantity | Speed | Power | |
| Name | Power | ||||||
| Back part making machine | CX20-50 type 2 grinding head | 3260*1500 | Flat belt motor | 1.5 kW | 1 | 0-1800 mm | 32.24KW |
| Grinding head motor | 15 kW | 2 | 1400 rpm | ||||
| Lifting the grinding head Bipolar motor | 0.37 kW | 2 | 1400 rpm | ||||
| Pneumatic Automatic Turning Machine | Type CX20-50 | 2907*2100 | Revolution engine | 0.37 kW | 2 | 1400 rpm | 0.74 kW |
| Grinding machine for front thickness | CX20-50 type 6 grinding heads | 7160*1500 | Surface Grinding Disc Motor | 15 kW | 2 | 1400 rpm | 51.94 kW |
| Disc lifting motor for surface grinding | 0.37 kW | 2 | 1400 rpm | ||||
| Side grinding disc motor | 5.5 kW | 2 | 1400 rpm | ||||
| Grinding motor for chamfering | 4 kW | 2 | 1400 rpm | ||||
| Flat belt motor | 2.2 kW | 1 | 0-1800 mm | ||||
| Pneumatic polishing machine | CX20-50 type 9 polishing head | 8160*1500 | Flat Polishing Wheel Motor | 5.5 kW | 4 | 960 rpm | 37.32 kW |
| Side polishing wheel motor | 3 kW | 3 | 1400 rpm | ||||
| Chamfering motor | 1.5 kW | 2 | 1400 rpm | ||||
| Flat belt motor | 2.2 kW | 1 | 0-1800 mm | ||||
| Engine side belt | 0.37 kW | 1 | 1400 rpm | ||||
| Cleaning brush motor | 0.75 kW | 1 | 1400 rpm | ||||
| Total 122.24 kW | |||||||
| Maximum grinding performance | Width 450 mm*Height 200 mm | ||||||
| Minimum grinding characteristics | Width 150 mm*Height 100 mm | ||||||
| Exit | 660 meters per shift in 10 hours | ||||||
| Water consumption | 50 tons of circulating water per hour | ||||||
| Stainless steel plate for side cover and engine cover of the whole set of equipment | |||||||
| Product name and specifications | Unit | Quantity (Unit) | |||||
| 1.CX20-50 type curbstone thickness determination, plate rotation, grinding, polishing combination machine | Kit | 1 | |||||
| One set includes the following products: | |||||||
| CX20-50 type 2 grinding head for back thickness processing | A unit of measurement | 1 | |||||
| Pneumatic Automatic Turning Machine Type CX20-50 | A unit of measurement | 1 | |||||
| 1.CX20-50 type curbstone thickness determination, plate rotation, grinding, polishing combination machine | Unit | 1 | |||||
| CX20-50 9 Head Pneumatic Front Side Chamfering Polishing Machine | Unit | 1 | |||||
It can use various materials such as stone flour, fly ash, slag, crushed stone, sand, construction waste, etc. as raw materials, and through the self-created vibration and high-pressure extrusion process, the products can be formed in a very short time. This molding process refers to pure physical molding without sintering, which meets modern social requirements for environmentally friendly and high-quality development. Curb brick making machine produces a wide range of products including but not limited to permeable bricks, antique bricks, hydraulic bricks, channel bricks, blind bricks, colored bricks, hollow bricks, polycarbonate imitation stone bricks, artificial stones, curb stones, etc., which are widely used in urban construction and development.
Product Features of Curb Stone Making Machine:
1. The curbstone making machine adopts advanced CNC technology, which can automate production, reduce manual intervention, and improve production efficiency. Its grinding wheel is made of high quality materials, provides good grinding effect, and can quickly polish the smooth and even surface of the stone, improving the quality of the product.
2. Environmental protection: The curb brick making machine uses environmentally friendly materials as the main raw materials, produces less waste in the production process, and can be recycled, which meets the current trend of green building development.
3. High efficiency and energy saving: Energy-saving equipment with automatic energy management and energy-saving and consumption-reduction technologies can maximize the protection of the environment, ensuring high energy efficiency in the brick production process and reducing emissions at the same time, which has the dual effect of energy saving and emission reduction.
4. Easy to operate: The curb stone making machine adopts a modular structure, and its operation is simple and straightforward. General staff can operate it effectively with simple training.
General: Curb brick making machine plays an indispensable role in the production and production of curb bricks. It is an efficient, stable, reliable, energy-saving and environmentally friendly mechanical equipment.
